Ceiling T Bar Roll Forming Machine

This equipment is based on cold roll-forming technology. It processes metal coils into standard T-shaped ceiling beams. The coils are typically made of galvanized steel or aluminum. The production line has several key parts. These include an uncoiling unit, a guiding device, and a roll-forming station. It also has a precision cutting system and a collection unit. The machine can perform additional steps like punching holes. It is controlled by a Programmable Logic Controller (PLC). Operators can use the touchscreen to adjust settings like speed and length. This ensures the final products have stable and consistent dimensions.

Ceiling T Bar Roll Forming Machine’s Application Scenarios

Architectural Decoration: The machine makes ceiling grid systems in large quantities. These systems are used in offices, shopping centers, and hospitals.

Building Material Factories: Factories add this machine to their production lines. It helps them meet orders for custom sizes and specifications.

Prefabricated Construction: The machine supplies standard metal beams. These beams are used in modern modular interior construction projects.

Key Parameters

Material: It works with galvanized steel or aluminum coils. The material thickness ranges from 0.3 to 0.8 mm.

Speed: The production speed is between 15 and 30 meters per minute.

Product Size: The height of the T-bar can be adjusted from 20 to 60 mm.

Cutting Precision: The cutting accuracy is within ±0.5 mm.

Power: The main motor uses 7.5 to 11 kW of power.

Control: It uses a PLC system with a touchscreen interface for operation.

Advantages

The Ceiling T Bar Roll Forming Machine is highly efficient and automated. It runs continuously at high speed. This requires very little manual work and greatly increases output.

It produces precise and consistent results. The PLC control and precision tooling ensure every product has accurate dimensions. Quality is uniform across large production batches.

The machine is flexible. Operators can easily adjust it to make beams of different sizes and lengths. It can also work with different types of metal.

Using this machine is cost-effective. It reduces material waste and lowers labor costs. It provides a strong return on investment for factories that need mass production.

The machine is built to last. Its strong construction and quality parts ensure reliable operation over a long period. It also requires little maintenance.

The machine can have added functions. Factories can choose to include punching or embossing steps in the same line. This makes the whole production process smoother.
